User's Manual Electric Bike
Section I - Mechanical Components Operation, Maintenance, & Safety
Contents:
1.Conditions for Riding This Electric bicycle
2. Saddle and Handlebar Set-Up
3. Safe Cycling and Safety Tips
4. Routine Maintenance Checks and Lubrication
5. Assembly Instructions
1. Riding Conditions
This pedal electric assistance bicycle is designed for riding on road, or paved surfaces
where the tires have firm contact with the riding surface. This e-bike must be properly
maintained according to the instructions found within this manual. The maximum
weight of the rider and load is 2201bs (100kgs).
WARNING! The owner/rider assumes the risk for personal injury, damage,
or losses. If the conditions in this manual are breached, the warranty will be
void automatically.
2. Saddle Set-Up, Adjustment
The Valen saddle is installed from the factory. It is a fixed position saddle (similar to a
traditional motorcycle seat), and is not adjustable.
The rider moves/slides forwards/ back and a bit from side-to-side to comfortably
and safely ride and control the ebike.
3. Safe Cycling and Safety Tips
3.1 Pre-Ride Check Points
Before you ride your pedal electric assistance bicycle always make sure it is in a safe
operating condition. Particularly check that your:
Nuts, bolts, quick-release and parts are fastened tight, not worn, or damaged.
Riding position is comfortable and unencumbered.
Brakes are operating effectively.
Steering is free with no excessive play.
Wheels run true and hub bearings are correctly adjusted.
Wheels are properly secured and locked to frame/fork.
Tires are in good condition and inflated to correct pressure (tire pressure in on
tire sidewall - do not exceed max tire pressure).
Pedals are securely tightened to pedal cranks.
All reflectors are in position and secure.
3
