Transport handles
Fig.8
A pair of handles fitting on to the top right and left hand sides of the BB
51 for convenient portability can be supplied as accessories (Order No.
32.825.0001).
• Insert and tighten the tommy screws G together with the transport
handle TG in the threaded borings (cf. arrow in Fig.8).
The handles can be left on the BB 51. They increase the overall width of
space required for the machine on the bench by approx. 115 mm.
Cleaning
!
Do not clean the BB 51 with running water.
Lethal hazard of electric shock!
Use only a damp rag.
Solvents must not be used, as they would wash out the grease
packing.
Cleaning the drawer recess
Fig.9
From time to time the recess containing the drawer must be cleaned.
A regular visual check on the state of the recess should be made.
• Pull out the mains plug.
• Pull the drawer out to the stop.
• Remove the inserted receptacle.
• Loosen but do not remove the two cheesehead screws ZS with
an Allan key AF4 Fig.9
• Slide the two cheesehead screws ZS together with the plate PL
fitted behind the drawer to the left.
• Take out the drawer.
The recess can now be cleaned.
Follow the same procedure in reverse to reassemble.
17.12.1998 © Retsch GmbH 16 Doc. No. GB 98.056.9999
