WHEEL ASSEMBLY
2
SUSPENSION ASSEMBLY
3
★52
OUTER WHEEL
CHROME
14
FRONT
SUSPENSION
SEMIGLOSS
BLACK
15
REAR
SUSPENSION
SEMIGLOSS BLACK
(PAINT SHADED AREA STEEL)
SEMIGLOSS
BLACK
ALUMINUM
ALUMINUM
ALUMINUM
ALUMINUM
SEMIGLOSS BLACK
ALUMINUM
TIRE
18
INNER WHEEL
SEMIGLOSS
BLACK
FRONT
REAR
