REVENT RVM80 - Page 12

11
12.) Press and bend the final securing tabs flat against ceiling to lock the FAN in
place.
final securing tabs
13.) Align TRIM RING notch to vent (DAMPER) position. Attach TRIM RING to
FAN. TRIM RING attaches to FAN body and clicks into place when secure.
sheetrock
(ceiling)
apply even
pressure to
each side of
securing tab
11.) Once connected, reattach the electrical enclosure.
reattach set
screw
plug in fan
connector
slide
ceiling
TRIM RING
FAN
final securing tabs
notch
