Reverso Outboard Flushing System 1.5 User Manual

16
Version B Dimensions: 3 Engine Setup
Water Outlet to
each Engine
Water Inlet
Push to
Start
Power Wires
74.8 2.94 93.2 3.67
93.2 3.67 98.8 3.89
51.8 2.04
12.7
.50
254
10.00
12.7
.50
359.9 14.17
Deutsch Connector for
Remote Switch
51.8 2.04
119.6
4.71
Outboard Flushing System
OFS-3-12
C
DO NOT SCALE DRAWING
OFS-3-12-ER-0616
SHEET 1 OF 1
6/6/2016
JC
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:8
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
REVERSO PUMPS
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
DIMENSIONS ARE IN INCHES TOLERANCES: FRACTIONAL
1/64
ANGULAR: MACH
BEND
0.2
TWO PLACE DECIMAL
.01
THREE PLACE DECIMAL
.005
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
REVERSO PUMPS
ANY REPRODUCTION IN PART OR
AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF
REVERSO PUMPS
IS PROHIBITED.
Part #: 35-3858-01
All Dimensions for Reference Only
Secondary Dimensions in Centimeters
TECHNICAL SPECIFICATIONS Port Size - Inlet: 1/2" Hose Barb
Outlet: 3/8" Hose Barb
Weight - 8 lbs.
Power - 12 Volt
JC
9/10/2015
OFS V1.0 with V1.5 EBOX (REV. B)

Reverso Outboard Flushing System 1.5 Specifications

General

Brand	Reverso
Model	Outboard Flushing System 1.5
Category	Boating Equipment
Language	English
