Reverso Outboard Flushing System 1.5 User Manual

5
Reverso Pumps, Inc. www.reversopumps.com | contact@reversopumps.com | Ph: (954) 522-0882
Technical Specications, Electrical, and Installation
Basic Features
• 12or24Volt
• 2,3,or4Enginesetup
• StartbuttonwithLEDstatusindicator
• 3’inlethosekitincluded
Optional Features
• RemoteSwitchKitwithLEDstatusindicator.Availablein
lengthsof3,6,9,12,15and18feet
• InletHoseKit.Availableinhoselengthsof1,2,3,6,and
9feet
Primary Inspection
• Upondeliveryinspectthesystemforanydamagethat
mayhaveoccurredduringshipment.
• Iftheunitisdamagedupondelivery,contactthe
shippingcompanyimmediately.
Mounting
• Mountingholes:Ø3/16”
• Orientation:Anydirectionon
aatsurfaceofthebulkhead
oraccessoriescompartment,
exceptupsidedown.
Electrical
• Installationmustincludeprotectionwith5Afuseor
breaker(providedbyinstaller).
• ONLY CONNECT BLACK (-) AND RED (+) WIRES
TO SAME RESPECTIVE COLOR. DAMAGE CAN
OCCUR TO THE SYSTEM IF THE WIRES ARE
CROSSED.
• Installationofunitshouldonlybeperformedby
qualiedelectricianwhohavethoroughlyreadand
understandstheinstallationinstructionscoveredin
thismanualandadheretoABYCrequirements.
• Toavoidtheriskofharmorinjury,makesurethat
thepowersupplyisdisconnected.Ensurethat
thepowersupplyisatzerovoltswithamultimeter
beforemakinganyelectricalconnections.
• Besurethatthepowersourceavailablematches
thepowerrequirements.
Connection to Engines
Hose:Smallerthantherequireddiameterhoseis
notrecommended.Choosettingswhichtthe
appropriatehosesize.Thehosewillrunfromthe
system,throughtheoutboardloom,andtotheengine.
Locatetheushingportontheengine,splittheline,
andconnectthehose.Or,choosetoinstallatee.
Important: Sealed Water Inlet
Incorporateasealedcapforthewaterinlettoblock
anybackow.Chooseoneofthefollowingways:
• InstalltheInletHoseKitwhichincludesacapon
thehoseendalready(shownbelow).
• IftheInletHoseKitisnotused,analternativecan
beabulkheadcap,quickdisconnect,orother
sealedttingprovidedbytheinstaller.
Technical Specications
Voltage 12V or 24V
Max. Amp. Draw
3A / 12V
1.5A / 24V
Water Inlet Hose 3/4”
Water Outlet
To Engine
3/8” hose barb, or 1/2” hose barb for
engines over 300HP
Dimensions
2 Engine Setup
A 10.5” / 267 mm
B 10” / 254 mm
C 4.7” / 119 mm
Dimensions
3 Engine Setup
A 14.17” / 360 mm
B 10” / 267 mm
C 4.7” / 119 mm
Dimensions
4 Engine Setup
A 17.84” / 453 mm
B 10” / 267 mm
C 4.7” / 119 mm
Dimensions
5 Engine Setup
A 21.5” / 546 mm
B 10” / 267 mm
C 4.7” / 119 mm
3
/
4
” ID
3
/
8
” ID
1
/
2
” ID
3/8” inner diameter hose is required
for water outlet (to engines).
Reinforced hose is recommended.
On the version designed for
engines over 300HP, 1/2” inner
diameter hose is required for water
outlet (to engines). Reinforced
hose is recommended.
3/4” inner diameter hose is required
for water inlet.
Capped tting on the
Inlet Hose Kit
