Pඖ

ඖ

in Assignments

Pin 1 RED VIDEO 9 

2 GREEN VIDEO 10 SIGNAL CABLE DETECT

3 BLUE VIDEO 11 GROUND

4 GROUND 12 SDA(for DDC)

5 GROUND 13 H-SYNC.(or H+V SYNC.)

6 RED GROUND 14 V-SYNC.

7 GREEN GROUND 15 SCL(for DDC)

8 BLUE GROUND 

D-SUB

ඖ

Accessories

1. Power cord.

2. Power adaptor

3. User manual.

4. VGA(RGB-PC) cable.

5. Stand & FS4x10 screws 3EA.

6. DVI cable (Optional).

7. Stereo cable (Optional).

8. Wall mount (Optional).

- 18 -G
