Instruments and operating elements
Instruments and Operating Elements (The individual items can vary slightly depending on model)
1 Speedometer
2 Revolution counter
3 High beam control lamp
(see pg. 8)
4 Generator (see pg. 8)
5 Oil pressure pilot light (see pg. 8)
6 Pilot light brake fluid level (see pg.)
7 Steering fork lock
8 Blinker control lamp
(see pg. 8)
9 Pedal adjustment (see pg. 12)
10 Brake pedal
11 Switch device
(see pg. 7)
12 Voltage indicator (see pg. 9)
13 Coolant temperature indicator
and Oil temperature indicator
(see pg. 8)
14 Ignition lock (see pg. 7)
12
11
1 2
13
14
15
16
3
4
5
6
7
8
9
10
17
18
15 Fuel gauge (see pg. 9)
16 Warning blinker
17 Clutch pedal
18 Handbrake lever
