8. Wire Binding
• Load the rear cover onto the wire element and lower it towards
the front of the machine. [Fig. 8]
• Load the front cover onto the wire element.
• Load the internal sheets onto the wire element, repeating until all
are loaded.
• Open the hinged cover at the front of the machine to reveal the
wire binding channel.
• Support the document whilst lifting the wire element off the wire
support feature.
• Continue to support the document whilst inserting the wire
element, open face downwards, into the wire binding channel.
[Fig. 9]
• Pull the handle down to close the binding jaws then return the
handle to the vertical position.
• Remove the bound document and flip the rear cover to the back
of the document. The seam of the closed wire element should be
on the inside of the rear cover and not on the outside of the
document.
9. Emptying the Waste Tray
Important: The waste tray must ONLY be emptied with the machine
supported in a upright position.
• Stand the machine upright.
• Unclip the tray from the underside of the machine. [Fig. 11]
• When refitting the tray ensure that it clicks firmly into place before
returning the machine to normal operation.
The tray has a scale to show when it is full. For best results, empty it
regularly.
10. Storage
• Close all open lids.
• Lower the handle, if raised. The handle must be locked in the
closed position before using it as a carry handle (WB655 only).
The machine incorporates feet at the rear to allow vertical storage.
[Fig. 12]
11. Refitting the Document Support Lid
If the document support lid becomes detached from the machine, refit
it as follows:
• Align the hinges up with the recesses in the machine. [Fig. 10]
• Squeeze one of the outer hinges inwards and locate in its
corresponding recess. Repeat for the other outer hinge.
12. Security
• A Security Slot is fitted for use with leading makes of security
leash. E.g.: Kensington Microsaver ( ).
Technical data subject to change without notification
Technical Data WB655
Operation mode
manual
Max. binding size
DIN A4 (max. 310mm)
Hole pitch US Pitch 9/16” / 14.28mm
Number of punch slots 34 (2 selectable)
Margin depth fixed
Punching - paper (80gsm) max. 20
Punching - plastic foils (0.2mm) max. 3
Min. wire diameter 5mm
Max. wire diameter 14mm
Max. document size (sheets) 130 - 140
Net weight (kg)
12.5
Dimensions (cm)
43x44x19
WB605
34 (fixed)
max. 15
max. 2
10.5
