REXROTH DIAX04 User Manual

DIAX04 ELS-06VRS About this Documentation
DOK-DIAX04-ELS-06VRS**-WA01-EN-P
Summary of Documentation - Box
Order designation:
DOK-DIAX04-ELS-06VRS**-FK01-EN-P
Order designation:
DOK-DIAX04-ELS-06VRS**-PA01-EN-P
Order designation:
DOK-DIAX04-ELS-06VRS**-WA01-EN-P
Order designation:
DOK-DIAX04-ELS-06VRS**-FV01-EN-P
Order designation:
DOK-DIAX04-ELS-06VRS**-IF01-EN-P
28280 1
FK
28280 1
PA
28280 1
WA
28280 1
FV
28280 1
IF
Functional Description:
Description of all implemented Function
based on SERCOS-Parameters
Parameter
Description:
A description of all parameters
used in the firmware
Troubleshooting
Guide:
-Explanation of the diagnostic states
-How to proceed when eliminating faults
Firmware Version Notes:
Description of new and changed functions
in terms of the derivatives:
-FWA-DIAX04-ELS-06VRS-MS
Drive
Configuration:
-Determining the motor type
-Choosing the motor – motor feedback
combination
-Choosing the desired function of the
drive control device
Order designation
DOK-DIAX04-ELS-06VRS**-6001-EN-P
(6-:),)04
CD: DRIVEHELP
Collection of Windows help systems which
contain documents on firmware derivatives
Order designation:
DOK-GENERL-DRIVEHELP**-GExx-MS-D0600
