RFX-RMR Issue 1.0 page 9 of 41
No. of Channels
2
Sub-Carriers
Audio1 4.5 to 5.1MHz, Audio2 5.5 to 6.2MHz
(selectable by front panel control)
De-emphasis
75 µS
Levels
+9dBm balanced line level out, for 200kHz peak-to-peak deviation.
Audio Performance
(analog receiver)
Frequency Response
±1.0dB 50Hz to 12kHz
Distortion
2% max.
Signal-to-Noise
50dB
Control and Monitoring
Menu selectable via the front panel control
COFDM demodulator / MPEG 2 decoder parameters
RF Received signal level
CSI
BER
Summary front panel alarm / comprehensive internal lock alarms
Power Supply
11 to 18V DC. 30 Watts
Mechanical Interface
Tripods, mast, scaffold and special mounts available.
Size
2 U rack mount, Depth 350mm
Weight
7.0kg
Environmental
Safe use: -20° to +50°C
To spec: -10° to +45°C
Altitude: 4500m
Humidity: 95% long term
Specifications may alter at the discretion of RF Central or to meet customer specific requirements.
