RF Central RFX-RMR - RFX-RMR SPECIFICATIONS

RFX-RMR Issue 1.0 page 8 of 41
3 SPECIFICATIONS
Frequency Band
1.97 – 2.50GHz band
Tuning Range
As per US BAS allocation (current and future plans)
Receiver Noise Factor
4dB (nom.)
IF Frequencies
1
st
IF In the range 600-1500MHz
2
nd
IF 70MHz
Digital Receiver Specifications
Receiver Threshold
-92dBm to BER 10
-5
(nom., QPSK)
Receive Antenna
Compatible with all RF Central antennas
Demodulation
COFDM DVB-T 2k
Demodulation Modes
QPSK, 16QAM, 64QAM
FEC:
1
/
2
2
/
3
3
/
4
5
/
6
7
/
8
Guard interval:
1
/
32
1
/
16
1
/
8
1
/
4
Data Rate
4.98 to 31.7 Mbit/s (automatic selection)
Bandwidth
8MHz (7 & 6MHz automatic selection)
Decoding Options
MPEG 2 4:2:0/4:2:2 high quality video (DVB standard)
Latency
Selectable to less than 2 frames minimum, Tx to Rx
Video Output
Digital: SDI 270Mbit/s
Analog: Y/C component (qty 1) or composite (PAL/NTSC) (qty
2)
Genlock
Optional (PAL/NTSC)
ASI Output
ASI transport stream (selectable 188, 204, byte)
Audio Output
Digital: 2 x AES3 outputs
Analog: 2 x stereo / 4 x mono outputs
Analog Receiver Specifications
Video Performance
Signal-to-Noise
55dB min. (LW)
LF Noise
50dB min.
Frequency Response
2.5dB to 5.8GHz
Differential Phase
2 degrees
Differential Gain
2%
Field tilt
3%K
Chrom/Lum Gain
2dB
Chrom/Lum Delay
25ns
Linearity
2.5%
Audio Performance
