B PA150 PARTS LIST
Ref. Description Part Number
NOTE - ALL COMPONENTS FOR WHICH REF IS ACCOMPANIED
WITH AN ASTERIX (*) ARE USED ONLY IN HIGH POWER MODELS (PA150XH)
C1 CAP 10N 10% 50V X7R RAD.2 46/2001/010N
C2 CAP 4N7 5% 400V MKT RAD.2 47/2040/04N7
C3 CAP 10U 35V RAD ELECTRO 41/2001/010U
C4 CAP 10N 10% 50V X7R RAD.2 46/2001/010N
C5 CAP 1N0 5% 63V NPO SM1206 46/3300/01N0
C6 CAP 1N0 5% 63V NPO SM1206 46/3300/01N0
C7 CAP 100N 10% 50V X7R RAD.2 46/2001/100N
C8 CAP 10N 10% 50V X7R RAD.2 46/2001/010N
C14 CAP 6.8U 20% 25V SOLID AL 41/2225/06U8
C15 CAP 100N 10% 50V X7R RAD.2 46/2001/100N
C16 CAP 100N 10% 63V X7R 1206 46/3310/100N
C17 CAP 1N0 500V MICA SM2220 48/3003/01N0
C18 CAP 1N0 500V MICA SM2220 48/3003/01N0
C29* CAP 6.8U 20% 25V SOLID AL 41/2225/06U8
C30* CAP 100N 10% 50V X7R RAD.2 46/2001/100N
C31* CAP 100N 10% 63V X7R 1206 46/3310/100N
C32* CAP 1N0 500V MICA SM2220 48/3003/01N0
C33* CAP 1N0 500V MICA SM2220 48/3003/01N0
C43* CAP 12P 500V MICA SM1210 48/3003/012P
C44* CAP 12P 500V MICA SM1210 48/3003/012P
C45* CAP 12P 500V MICA SM1210 48/3003/012P
C46* CAP 12P 500V MICA SM1210 48/3003/012P
C47* CAP 12P 500V MICA SM1210 48/3003/012P
C48* CAP 12P 500V MICA SM1210 48/3003/012P
C49* CAP 12P 500V MICA SM1210 48/3003/012P
C50* CAP 12P 500V MICA SM1210 48/3003/012P
C51 CAP 10P 5% 63V NPO SM 1206 46/3300/010P
C52 CAP 10P 5% 63V NPO SM1206 46/3300/010P
C53 CAP 1N0 5% 63V NPO SM1206 46/3300/01N0
C54 CAP 1N0 5% 63V NPO SM1206 46/3300/01N0
C55 CAP 1N0 5% 100V NPO RAD.2 46/2000/01N0
C56 CAP 1N0 5% 100V NPO RAD.2 46/2000/01N0
C57 CAP 1N0 5% 100V NPO RAD.2 46/2000/01N0
C58 CAP 1N0 5% 100V NPO RAD.2 46/2000/01N0
C59 CAP 1N0 5% 100V NPO RAD.2 46/2000/01N0
C60 CAP 1N0 5% 100V NPO RAD.2 46/2000/01N0
C61 CAP 1N0 5% 100V NPO RAD.2 46/2000/01N0
D1 DIODE SHTKY BAT17 SOT23 21/3030/0017
D2 DIODE SILICON 1N4148 21/1010/4148
D3 DIODE SHTKY BAT17 SOT23 21/3030/0017
L1 IND 1U0 10% CHOKE SM1206 37/3320/01U0
L2 INDUCTOR 1UH AXIAL 37/2021/001U
L3 FERRITE BEAD 3x4x1 4S2 37/1022/0001
L4 COIL AIR COR 7T 1.5P 6.35ID 37/1635/1507
L5 IND MOLDED 6.5 TURN 37/2021/0006
L6 IND MOLDED 6.5 TURN 37/2021/0006
L7* INDUCTOR 1UH AXIAL 37/2021/001U
L8* FERRITE BEAD 3x4x14S2 37/1022/0001
