5 ELECTRICAL SPECIFICATIONS
4.3.2 Test Points (DB9 Connector)
Forward Power Pin 8 + Gnd (pin 1)
Reverse Power Pin 4 + Gnd (pin 1)
Collector Current Pin 6, Pin 2 + Vcc 13.2Vdc
5 Electrical Specifications
5.1 Power Requirements
Operating Voltage - 10.5 to 16 Vdc with output power reduced below 12.5 Vdc.
Current Drain @ 13.2 Vdc - 10 Amps Max at 50 watts. 100 mA Max standby
Polarity - Negative Ground
5.2 Frequency Range
Frequency 50 Watt 100 Watt
136-156MHz PA150A PA150AH
154-174 MHz PA150B PA150BH
5.3 Nominal Antenna Impedance
50O
5.4 Output Power
25 to 100 watts adjustable
5.5 Transmit Duty Cycle
With Free Air Circulation
50 Watts - 100% to 40 deg. C
100 Watts - 50% to 40 deg. C
With Fan Module
50-100 Watts - 100% to 50 deg. C
5.6 Spurious and Harmonics
Less than 0.25uW
