5.7 Maximum Heatsink Temperature
90 degrees C.
5.8 ALC Output
The ALC is intended for connection to the T150. It supplies a voltage which
decreases with increasing power or temperature.
5.9 Mis-Match Protection
The amplifier is protected from damage when operating into a VSWR of 10/1 at
all phase angles.
6 Connectors
6.1 Antenna Connector
Type N Female mounted on the module rear panel
6.2 Power and I/O Connector
25 pin “D” Male mounted on the rear panel
6.3 Test Connector
9 pin “D” Female mounted on the front panel.
