B PA150 Parts List
Ref Description Part Number
R32 RES 33K 5% 0.25W AXIAL 51/1040/033K
R34 RES 220 5% 2W AXIAL 51/1052/0220
R35 RES 10 5% 0.25W AXIAL 51/1040/0010
R36 RES 10 5% 0.25W AXIAL 51/1040/0010
R37 RES 220 5% 2W AXIAL 51/1052/0220
R38* RES 220 5% 2W AXIAL 51/1052/0220
R39* RES 10 5% 0.25W AXIAL 51/1040/0010
R40* RES 10 5% 0.25W AXIAL 51/1040/0010
R41* RES 220 5% 2W AXIAL 51/1052/0220
R42* RES 12R 5% 2W AXIAL 51/1052/0012
R43 RES 12R 5% 2W AXIAL 51/1052/0012
R50(P2) RES 100 5% 0.25W AXIAL 51/1040/0100
RT1 THERMISTOR 54/0400/0080
RV1 TRIMPOT 10K 1 TURN VERT 53/1020/010K
RV2 TRIMPOT 10K 1 TURN VERT 53/1020/010K
U1 IC VOLT REG 78L08 TO 92M 25/2040/78L08
U2 IC QUAD OP AMP TLC274 25/2050/274C
PA150A 135-156 MHz Parts
These parts fitted to PA150A & AH
C9 CAP 160P 500V MICA SM1812 48/3003/160P
C10 CAP 160P 500V MICA SM1812 48/3003/160P
C12 CAP 120P 500V MICA SM1812 48/3003/120P
C13 CAP 27P 500V MICA SM1210 48/3003/027P
C19 CAP 68P 500V MICA SM1210 48/3003/068P
C20 CAP 68P 500V MICA SM1210 48/3003/068P
C21 CAP 510P 500V MICA SM1812 48/3003/510P
C22 CAP 330P 500V MICA SM1812 48/3003/330P
C23 CAP 270P 500V MICA SM1812 48/3003/270P
C39 CAP 39P 500V MICA SM1210 48/3003/039P
C40 CAP 39P 500V MICA SM1210 48/3003/039P
C41 CAP 10P 500V MICA SM1210 48/3003/010P
C42 CAP 12P 500V MICA SM1210 48/3003/012P
These additional parts used on PA150AH ONLY
C24* CAP 160P 500V MICA SM1812 48/3003/160P
C25* CAP 160P 500V MICA SM1812 48/3003/160P
C27* CAP 120P 500V MICA SM1812 48/3003/120P
C28* CAP 27P 500V MICA SM1210 48/3003/027P
C34* CAP 68P 500V MICA SM1210 48/3003/068P
C35* CAP 68P 500V MICA SM1210 48/3003/068P
C36* CAP 510P 500V MICA SM1812 48/3003/510P
C37* CAP 330P 500V MICA SM1812 48/3003/330P
C38* CAP 270P 500V MICA SM1812 48/3003/270P
To Next Page
