4 Rheem Heating, Cooling and Water Heating
Model Numbers
80°F [26.5°C] DB/67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
Sound
Rating
dB
Indoor
CFM [L/s]
Outdoor
Unit
13AJM
Indoor
Coil and/or
Air Handler
Total
Capacity
BTU/H [kW]
Net
Sensible
BTU/H [kW]
Net
Latent
BTU/H [kW]
EER SEER
24
RCFL-H*2417 (RGGE-07?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.95 14.00 74 800 [378]
RCFL-H*2417 (RGJD-06?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.90 14.00 74 800 [378]
RCFL-H*2417 (RGJD-07?MCK?) 23,400 [6.9] 17,400 [5.1] 6,000 [1.8] 11.80 13.50 74 800 [378]
RCFL-H*2417 (RGJF-06?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 12.05 14.00 74 825 [389]
RCFL-H*2417 (RGJF-07?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.95 14.00 74 800 [378]
RCFL-H*2417 (RGLR-07?AMK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 12.05 14.00 74 800 [378]
RCFL-H*2417 (RGLT-07?AME?) 23,000 [6.7] 16,600 [4.9] 6,400 [1.9] 11.50 14.00 74 675 [319]
RCFL-H*2417 (RGPE-05?BMK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 74 800 [378]
RCFL-H*2417 (RGPE-07?AMK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 74 825 [389]
RCFL-H*2417 (RGPR-05?BMK?) 23,400 [6.9] 17,400 [5.1] 6,000 [1.8] 11.75 13.50 74 775 [366]
RCFL-H*2417 (RGPR-07?AMK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 12.00 14.00 74 800 [378]
RCFL-H*2417 (RGPT-05?BMK?) 23,800 [7.0] 17,900 [5.2] 5,900 [1.7] 11.50 13.50 74 850 [401]
RCFL-H*2417 (RGPT-07?AME?) 23,800 [7.0] 17,900 [5.2] 5,900 [1.7] 11.50 14.00 74 850 [401]
RCFL-H*2417 (RGRM-04?MAE?) 23,400 [6.9] 17,400 [5.1] 6,000 [1.8] 11.65 13.50 74 800 [378]
RCFL-H*2417 (RGRM-06?MAE?) 23,400 [6.9] 17,400 [5.1] 6,000 [1.8] 11.70 13.50 74 825 [389]
RCFL-H*2417 (RGRM-07?MAE?) 23,600 [6.9] 17,750 [5.2] 5,850 [1.7] 11.45 13.00 74 850 [401]
RCFL-H*2417 (RGTM-06?MAE?) 23,400 [6.9] 17,200 [5.0] 6,200 [1.8] 11.50 14.00 74 750 [354]
ROCA-070E03 (RCFL-H*2417) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 74 800 [378]
ROCA-070E04 (RCFL-H*2417) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 74 800 [378]
ROLA-070E03 (RCFL-H*2417) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 74 800 [378]
ROLA-070E04 (RCFL-H*2417) 23,200 [6.8] 16,950 [5.0] 6,250 [1.8] 11.50 14.00 74 725 [342]
RBHP-17 (RCHL-24A2) 22,000 [6.4] 15,850 [4.6] 6,150 [1.8] 11.50 14.00 74 800 [378]
RCQD-2417 (RGFE-06?MCK?) 23,800 [7.0] 18,750 [5.5] 5,050 [1.5] 11.50 13.50 74 800 [378]
RCQD-2417 (RGFE-07?MCK?) 23,800 [7.0] 18,750 [5.5] 5,050 [1.5] 11.50 13.50 74 825 [389]
RCQD-2417 (RGJF-06?MCK?) 24,000 [7.0] 18,950 [5.6] 5,050 [1.5] 11.50 13.50 74 825 [389]
RCQD-2417 (RGJF-07?MCK?) 23,800 [7.0] 18,750 [5.5] 5,050 [1.5] 11.50 13.50 74 800 [378]
RCQD-2417 (RGPE-05?BMK?) 24,000 [7.0] 18,950 [5.6] 5,050 [1.5] 11.50 13.50 74 800 [378]
RCQD-2417 (RGPE-07?AMK?) 24,000 [7.0] 18,950 [5.6] 5,050 [1.5] 11.50 14.00 74 825 [389]
RCQD-2417 (RGPR-05?BMK?) 23,600 [6.9] 18,400 [5.4] 5,200 [1.5] 11.50 13.50 74 750 [354]
RCQD-2417 (RGPR-07?AMK?) 24,000 [7.0] 18,950 [5.6] 5,050 [1.5] 11.50 14.00 74 800 [378]
RCQD-2417 (RGPT-05?BMK?) 24,400 [7.1] 19,650 [5.8] 4,750 [1.4] 11.50 13.50 74 900 [425]
RCQD-2417 (RGRM-04?MAE?) 23,800 [7.0] 18,750 [5.5] 5,050 [1.5] 11.50 13.50 74 800 [378]
RCQD-2417 (RGRM-06?MAE?) 23,800 [7.0] 18,750 [5.5] 5,050 [1.5] 11.50 13.50 74 825 [389]
RCQD-2417 (RGRM-07?MAE?) 23,800 [7.0] 18,750 [5.5] 5,050 [1.5] 11.50 13.50 74 800 [378]
RCQD-2417 (RGTM-06?MAE?) 23,800 [7.0] 18,750 [5.5] 5,050 [1.5] 11.50 13.50 74 825 [389]
ROCA-070E03 (RCQD-2417) 24,000 [7.0] 18,950 [5.6] 5,050 [1.5] 11.50 14.00 74 800 [378]
ROCA-070E04 (RCQD-2417) 24,000 [7.0] 18,950 [5.6] 5,050 [1.5] 11.50 14.00 74 800 [378]
ROLA-070E03 (RCQD-2417) 24,000 [7.0] 18,950 [5.6] 5,050 [1.5] 11.50 14.00 74 800 [378]
ROLA-070E04 (RCQD-2417) 23,600 [6.9] 18,350 [5.4] 5,250 [1.5] 11.50 13.50 74 725 [342]
RHKL-HM2417 (RCSL-H*2417) 23,800 [7.0] 17,900 [5.2] 5,900 [1.7] 12.00 14.00 74 850 [401]
RHLL-HM2417 (RCSL-H*2417) 23,600 [6.9] 17,500 [5.1] 6,100 [1.8] 12.35 14.50 74 775 [366]
RHSL-HM2417 (RCSL-H*2417) 23,200 [6.8] 17,250 [5.1] 5,950 [1.7] 11.25 13.00 74 800 [378]
30
RCFL-H*3617
➀
27,400 [8.0] 21,000 [6.2] 6,400 [1.9] 11.05 13.00 73 1,025 [484]
RHAL-FR30P 28,400 [8.3] 22,000 [6.4] 6,400 [1.9] 11.30 13.00 73 975 [460]
RHBL-FR36T 28,400 [8.3] 22,000 [6.4] 6,400 [1.9] 12.00 14.00 73 1,025 [484]
RCFL-A*3617 27,400 [8.0] 21,000 [6.2] 6,400 [1.9] 11.05 13.00 73 1,025 [484]
RCFL-A*3617 (RGFD-06?MCK?) 27,600 [8.1] 21,150 [6.2] 6,450 [1.9] 11.40 13.00 73 1,000 [472]
RCFL-A*3617 (RGFD-07?MCK?) 27,800 [8.1] 21,300 [6.2] 6,500 [1.9] 11.60 13.50 73 1,000 [472]
RCFL-A*3617 (RGFE-06?MCK?) 27,800 [8.1] 21,300 [6.2] 6,500 [1.9] 11.70 13.50 73 1,000 [472]
RCFL-A*3617 (RGFE-07?MCK?) 27,800 [8.1] 21,300 [6.2] 6,500 [1.9] 11.60 13.50 73 1,025 [484]
RCFL-A*3617 (RGGD-06?MCK?) 27,800 [8.1] 21,300 [6.2] 6,500 [1.9] 11.70 13.50 73 1,000 [472]
RCFL-A*3617 (RGGD-07?MCK?) 27,800 [8.1] 21,350 [6.3] 6,450 [1.9] 11.60 13.50 73 1,025 [484]
RCFL-A*3617 (RGGE-06?MCK?) 27,800 [8.1] 21,300 [6.2] 6,500 [1.9] 11.85 13.50 73 1,025 [484]
Rev.
6/30/10
Performance Data @ AHRI Standard Conditions—Cooling (con’t.)
➀ Highest sales volume tested combination required by D.O.E. test procedures. [ ] Designates Metric Conversions
