Rheem 801S Series User Manual

10
BOTTOM
TOP
LEFT SIDE FRONT RIGHT SIDE
GAS
CONNECTION
ELECTRICAL CONNECTION
LINE VOLTAGE
ELECTRICAL CONNECTION
LOW VOLTAGE
OPTIONAL GAS CONNECTION
OPTIONAL LOW VOLTAGE WIRING
OPTIONAL LINE VOLTAGE WIRING
A
I
R
F
L
O
W
RETURN
AIR
SUPPLY
AIR
HOT
MODEL A B C D E F RIGHT SIDE BACK TOP FRONT VENT
5 14 13 27/32 10 5/8 ༃ 11 1/2 1 7/8 0 4༄ 01 36༅ 85 lbs.
7 17 1/2 16 11/32 12 3/8 ༃ 15 2 1/2 0 3༄ 01 36༅ 105 lbs.
10 21 19 27/32 14 1/8 ༃ 18 1/2 2 1/2 0 0 0 1 3 6༅ 120 lbs.
12 24 1/2 23 11/32 15 7/8 ༃ 22 2 1/2 0 0 0 1 3 6༅ 140 lbs.
15 24 1/2 23 11/32 15 7/8 ༃ 22 2 1/2 0 0 0 1 3 6༅ 150 lbs.
༃MAY REQUIRE 3" TO 4" OR 3" TO 5" ADAPTER.
4" ADAPTER INCLUDED WITH (-)801P UNITS.
༄MAY BE 0" WITH TYPE B VENT.
༅MAY BE 1" WITH TYPE B VENT.
LEFT SIDE
REDUCED CLEARANCE (IN.)
SHIP
WGTS.
FIGURE 4
UPFLOW/HORIZONTAL DIMENSIONS
Location
REDUCED CLEARANCE (IN.)
Input A B C D E F
Left Right
Back Top Front Vent
Ship.
Side Side Wgts.
050 14 12
27
/32 10
5
/8 ➀ 11
1
/2 1
7
/8 0 4➁ 0 1 3 6➂ 85 lbs.
070 17
1
/2 16
11
/32 12
3
/8 ➀ 15 2
1
/2 0 3➁ 0 1 3 6➂ 105 lbs.
100 21 19
27
/32 14
1
/8 ➀ 18
1
/2 2
1
/2 0 0 0 1 3 6➂ 120 lbs.
120 24
1
/2 23
11
/32 15
7
/8 ➀ 22 2
1
/2 0 0 0 1 3 6➂ 140 lbs.
150 24
1
/2 23
11
/32 15
7
/8 ➀ 22 2
1
/2 0 0 0 1 3 6➂ 150 lbs.
CLEARANCE TO COMBUSTIBLE MATERIAL (INCHES) UPFLOW/HORIZONTAL MODELS
➀ May require 3” to 4” or 3” to 5” adapter. 4” adapter optional. ➁ May be 0” with type B vent. ➂ May be 1” with type B vent. *See furnace speck sheet for availability.
ST-A1220-04
