94
AIR FLOW PERFORMANCE
AIRFLOW
Low 732 [345] 695 [328] 669 [316] 639 [302] 605 [286] 547 [258] 512 [242] 487 [230]
Med. Lo 875 [413] 845 [399] 820 [387] 792 [374] 766 [362] 726 [343] 659 [311] 605 [286]
Med. Hi* 1073 [506] 1049 [495] 1004 [474] 975 [460] 943 [445] 900 [425] 864 [408] 798 [377]
High 1279 [604] 1239 [585] 1213 [572] 1174 [554] 1121 [529] 1069 [505] 1033 [488] 980 [463]
Low 830 [392] 793 [374] 755 [356] 705 [333] 654 [309] 599 [283] 544 [257] 496 [234]
Med. Lo 940 [444] 908 [429] 875 [413] 821 [387] 766 [362] 710 [335] 653 [308] 584 [276]
Med. Hi* 1168 [551] 1139 [538] 1109 [523] 1060 [500] 1010 [477] 942 [445] 874 [412] 802 [379]
High 1421 [671] 1385 [654] 1349 [637] 1291 [609] 1232 [581] 1147 [541] 1062 [501] 976 [461]
Low 852 [402] 827 [390] 802 [379] 752 [355] 701 [331] 662 [312] 623 [294] 580 [274]
Med. Lo 986 [465] 955 [451] 923 [436] 883 [417] 843 [398] 790 [373] 737 [348] 686 [324]
Med. Hi* 1238 [584] 1211 [372] 1183 [558] 1139 [538] 1094 [516] 1036 [489] 978 [462] 897 [423]
High 1493 [705] 1452 [1685] 1410 [665] 1364 [644] 1318 [622] 1257 [593] 1195 [564] 1084 [512]
Low 1313 [620] 1275 [602] 1236 [583] 1221 [576] 1184 [559] 1141 [538] 1098 [518] 1053 [497]
Med. Lo 1488 [702] 1452 [685] 1415 [668] 1384 [653] 1328 [627] 1279 [604] 1229 [580] 1170 [552]
Med. Hi* 1732 [817] 1704 [804] 1676 [791] 1630 [769] 1579 [745] 1498 [707] 1417 [669] 1343 [634]
High 1983 [936] 1929 [910] 1874 [884] 1810 [854] 1742 [822] 1663 [785] 1583 [747] 1477 [697]
Low 1329 [627] 1313 [620] 1296 [612] 1260 [595] 1224 [578] 1171 [553] 1117 [527] 1049 [495]
Med. Lo 1535 [724] 1498 [707] 1461 [690] 1422 [671] 1382 [652] 1325 [625] 1268 [598] 1203 [568]
Med. Hi* 1796 [848] 1748 [825] 1700 [802] 1656 [782] 1612 [761] 1536 [725] 1460 [689] 1370 [647]
High 2019 [953] 1961 [925] 1903 [898] 1843 [870] 1782 [841] 1687 [796] 1592 [751] 1489 [703]
Low 1249 [589] 1234 [582] 1219 [575] 1183 [558] 1146 [541] 1112 [525] 1078 [509] 1017 [580]
Med. Lo 1440 [680] 1429 [674] 1417 [669] 1381 [652] 1344 [634] 1313 [620] 1281 [605] 1221 [576]
Med. Hi* 1770 [835] 1750 [826] 1730 [816] 1696 [800] 1662 [784] 1611 [760] 1559 [736] 1463 [690]
High 2123 [1002] 2077 [980] 2031 [959] 1983 [936] 1934 [913] 1856 [876] 1777 [839] 1665 [786]
TABLE 19
AIR FLOW PERFORMANCE – (-)95P & (-)(-)95MSP SERIES MODELS
Model
Motor HP [W]
Blower Size
IN [MM]
CFM Air Delivery
External Static Pressure, ”W.C. [kPa]
Speed Tap 0.1 [0.02] 0.2 [0.05] 0.3 [0.07] 0.4 [0.10] 0.5 [0.12] 0.6 [0.15] 0.7 [0.17] 0.8 [0.19]
(-)95PA0401317MSA
&(-)(-)95MSP040B30A
1/4 [187]
11 x 7
[279 x 178]
(-)95PA0601317MSA
& (-)(-)95MSP060B30A
(-)95PA0701317MSA
& (-)(-)95MSP070B30A
(-)95PA0851521MSA
& (-)(-)95MSP085C50A
(-)95PA1001521MSA
& (-)(-)95MSP100C50A
(-)95PA1151524MSA
& (-)(-)95MSP115D50A
1/2 [373]
11 x 8
[279 x 203]
1/2 [373]
11 x 8
[279 x 203]
3/4 [559]
11 x 10
[279 x 254]
3/4 [559]
11 x 10
[279 x 254]
3/4 [559]
11 x 11
[279 x 279]
*Factory Setting For Heat
All shaded cells are valid heating settings. Do not use speed taps and/or static pressures which do not fall into the shaded cells on this table.
NOTE: Where maximum airflow is 1800 CFM or more, BOTH sides or the bottom must be used for the return air.
BLOWER SPEED SELECTIONS
The furnace controls have four active quick connect termi-
nals for connecting the motor speed leads. These are:
1. FAN — motor runs on this speed when the thermostat
is in the “FAN ON” position.
2. COOL — connect desired cooling speed.
3. HEAT — connect desired heating speed.
4. H/C (for heat/cool) — connect desired speed when
heating and cooling speed are the same.
In addition to the active motor terminals, there are two
motor parking terminals (labeled M1 and M2) available for
placing any unused motor taps. All unused motor taps
should be connected to either M1 or M2. These terminals
(M1 and M2) will not be energized under any condition.
IMPORTANT: Do not connect any motor speeds to “HEAT”
and/or “COOL” if you use the “HEAT/COOL” terminal.
5. If heating and continuous fan speed are the same,
“piggyback” jumper across “FAN” and “HEAT” termi-
nals.
If cooling speed and fan speed are desired to be the same,
this may be accomplished by not connecting “Y” to the in-
tegrated furnace control.
IMPORTANT: If desired for cool, fan and heat to all be
the same speed, then “piggyback” jumper “H/C” to
“FAN” and do not connect “Y” to the integrated fur-
nace control. Do not connect anything to “Heat” or
“Cool.”
See selection titled “Field Selections – Dipswitches” for
setting the heating and cooling blower off delay times.
