40
FIGURE 42
MANIFOLD PRESSURE READING
FIGURE 43
UPFLOW GROUNDING CONNECTIONS
JUNCTION
BOX
CONDENSATE
TRAP
CONTROL IS GROUNDED
WHEN ATTACHED TO BLOWER
LOW VOLTAGE
TERMINALS
IFC
MOUNTING
PLATE
BLOWER
COMPARTMENT
I409-3
