Rheem Manufacturing Company 5
NOTES: May require a 3" [76 mm] to 4" [102 mm] or 3" [76 mm] to 5" [127 mm] adapter.
May be 0" [0 mm] with type B vent.
May be 1" [25 mm] with type B vent.
Furnaces must be vented in accordance with the National Fuel Gas Code, ANSI Z223.1 and/or Can/CGA-B149 Installation Codes and in accordance with
local codes.
[ ] Designates Metric Conversions
HORIZONTAL DIMENSIONS
HORIZONTAL DIMENSIONS AND CLEARANCE TO COMBUSTIBLE MATERIAL (INCHES) [mm]
WARNING
THIS FURNACE IS NOT APPROVED
OR RECOMMENDED FOR INSTALLATION
ON ITS BACK, WITH ACCESS DOORS
FACING UPWARDS.
MODEL
RGPR-
A B C D E
REDUCED CLEARANCES (IN.) [mm]
05, 07A
17
1
/2 [445] 16
11
/32 [415] 12
3
/8 [314]
15 [381]
0
3 [76]
0 1 [25] 3 [76]
6 [152]
LEFT
SIDE
RIGHT
SIDE
BACK TOP FRONT VENT
SHIP. WGTS.
(LBS.) [Kg]
07B, 10
21 [533] 19
27
/32 [504] 14
1
/8 [359]
18
1
/2 [470]
0 0 0 1 [25] 3 [76]
6 [152]
120 [54.4]
110 [49.9]
12
24
1
/2 [622] 23
11
/32 [593] 15
7
/8 [403]
22 [559]
0 0 0 1 [25] 3 [76]
6 [152]
140 [63.5]
F
2
1
/2 [64]
2
1
/2 [64]
2
1
/2 [64]
NOTE: In horizontal configuration, return air cutout is not permitted.
