Rheem rH42 User Manual

29
Softener Parts List
To order repair parts call toll free 1-800-754-7027.
Manufactured and warranted by
Water Channel Partners
1890 Woodlane Drive
Woodbury, MN 55125
Questions? Call Toll Free 1-800-754-7027 or visit www.rheemwatertreatment.com
When you call, please be prepared to provide the model and serial number,
found on the rating decal inside the salt lid.
K
ey
No.
Part No. Description
16 7384625 Faceplate (order decal below)
17 7385566 Faceplate Decal
1
8
7
386839
S
alt Lid (order decal below)
¢
7386732 Instruction Decal
19 7386821 Top Cover
20 7351054 Power Supply, 24V DC
21 7386855 Cover, Brinewell
– 7386978
Brinewell Mounting Hardware Kit
(includes Key Nos. 22-24)
22
á
Wing Nut, 1/4-20
23
á
Spacer, 3/4” long
24
á
Screw, 1/4-20 x 1-1/2”
25 7214375 Brinewell
– 7331258
Overflow Hose Adaptor Kit
(includes Key Nos. 26-28)
26
á
Adaptor Elbow
27
á
Grommet
28
á
Hose Clamp
29 7310202 Repl. Brine Valve Assembly
30 7327568 Float, Stem & Guide Assembly
31 7139999 Drain Hose
¢ Not illustrated.
K
ey
No.
Part No. Description
– 7112963
D
istributor O-Ring Kit
(includes Key Nos. 1-3)
1
á
O-Ring, 2-7/8” x 3-1/4”
2
á
O-Ring, 13/16” x 1-1/16”
3
á
O-Ring, 2-3/4” x 3”
4 7077870 Top Distributor
5 7327584 Repl. Bottom Distributor
6 7265025 Filter Screen
– 7331177
Tank Neck Clamp Kit
(includes 2 ea. of Key Nos. 7 & 8)
7
á
Clamp Section (2 req.)
8
á
Retainer Clip (2 req.)
9 7247996 Repl. Resin Tank, 10” x 40”
10 0502272 Resin, 1 cu. ft.
11 7384659 Repl. Brine Tank (order badge below)
12 7386538 Badge, Rheem
13 7384641 Rim
14 7384633 Support, Faceplate
15 7386782
Repl. Electronic Control Board (PWA),
including status light
