OUTDOOR UNIT ROMH36AFXZJ
1. Specifications
1-1. Model: ROMH36AFXZJ
Type Inverter heat pump
Model name
ROMH36AFXZJ
Power source 1Ø 208/230 V 60 Hz
Available voltage range 187—264V
Connectable indoor unit
Number 2* to 4
Total capacity range 27,000 to 39,000 Btu/h
Combination of indoor unit
Non-duct
RIWH9AVFJ × 4
Duct
RIDH9AVFJ × 4
Mix
Capacity
Cooling
Rated
Btu/h 35,200
kW 10.3
Min.—Max.
Btu/h 11,000—38,000
kW 3.2—11.1
Heating
Rated
Btu/h 36,400
kW 10.68
Min.—Max.
Btu/h 11,000—42,000
kW 3.2—12.3
Input power
Cooling
Rated
kW
3.52 3.92 3.71
Max. 4.10 4.38 4.24
Heating
Rated 3.00 3.22 3.11
Max. 3.70 3.85 3.78
Current
Cooling
Rated A
15.4 17.1 15.9
Heating 13.1 15.1 14.1
EER Cooling Rated Btu/W 10.0 9.0 9.5
SEER *
1
Cooling - 18.0 16.0 17.0
COP Heating Rated W/W 3.56 3.32 3.44
HSPF *
1
Heating - 9.4 8.7 9.1
Starting current A 17.1
Maximum operating current *
2
A20.3
Fan
Type × Q'ty Propeller × 1
Airflow rate
Cooling
CFM (m
3
/h)
2,119 (3,600)
Heating 2,237 (3,800)
Motor
Type × Quantity DC motor × 1
Output W 100
Sound pressure level
Cooling
Rated dB (A)
53
Heating 55
Heat exchanger
Dimension (H × W × D) in (mm) 31-13/32 × 35-7/16 × 1-7/16 (798 × 900 × 36.38)
Fin pitch FPI 20
Rows × Stages 2 × 38
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue Fin)
Compressor
Type × Quantity DC twin rotary × 1
Motor output W 1,300
Refrigerant
Type R410A
Charge lb (g) 7 lb 1 oz (3,200)
Refrigerant oil
Type RB68
Amount
in
3
(cm
3
)
48.8 (800)
Enclosure
Material Painted galvanized steel
Color
Beige
(Approximate color of MUNSELL 10YR 7.5/1.0NN)
Dimensions
Net
(H × W × D) in (mm)
32-11/16 × 35-7/16 × 13 (830 × 900 × 330)
Gross 39-3/8 × 41-5/16 × 17-1/2 (1,000 × 1,050 × 445)
Weight
Net
lb (kg)
149 (68)
Gross 168 (76)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35) × 4
Gas Ø3/8 (Ø9.52) × 3 + Ø1/2 (Ø12.7) × 1
Method Flare
Pre-charge length (Total)
ft (m)
164 (50)**
Max. length (Total) 230 (70)
Max. length (Each) 82 (25)
Min. length (Total) 66 (20)
Min. length (Each) 16 (5)
Max. height difference between outdoor unit and each
indoor units
49 (15)
Max. height difference between indoor units 33 (10)
