69
PARTS REPLACEMENT
Parts
Parts Ordering
WARNING: For your safety, do not
attempt to disassemble, repair, or replace any
portion of this unit. Refer all repairs, service, and/
or adjustments to qualified service personnel.
Address all parts orders to the distributor or store
where the water heater was purchased. All parts
orders should include:
1. The model and serial number of the water
heater from the rating plate.
2. Specify the gas type (natural or LP) as marked
on the rating plate.
3. Parts description (as shown below) and number
of parts desired.
Direct-Vent Gas Components
Ref # Description
1 Control Board
2 Gas Valve
3 Burner Assembly
4 Blower Motor
5 Burner Manifold
6 Gas Inlet Connector
7 Water Control Body
8 Water Inlet Connector 3/4"
9 Drain Relief Valve
10 Hot Outlet Connector
11 Remote Control Terminal Block
12 Neutralization kit
13 Air Intake Connector
14 Flue Connector
15 Front Cover
