RHEONIK Messgeräte GmbH REV. I, Apr. 2004
.
Operation Manual RHE 07, 08, 11
Page
34
The configuration of the digital outputs and inputs has to be done in the standard menu under Setup
I/O =>> Dig.
In1 (Input 1) can be configured as Batch Start or Batch Stop.
In2 (Input 2) can be configured as Batch Start or Batch Stop.
The function of Out active=clsd or
open has no effect for the batch functions
(always setup as active clsd).
The valve is therefore always closed if there is a power failure on the batch system.
Preset and Prewarn- outputs have the status off, if the valves are open. The Error output has the
status off, if there is no error !
Out1 (output 1) can be configured Preset or Prewarn (or standard function)
Out2
(output 2) can be configured Preset or Prewarn (or standard function)
Out3 (output 3) can be configured Preset or Prewarn (or standard function)
6.3. Option code selection
Choose in the service and diagnosis menu the sub-menu-step Calibration Menu
.
Now press all 3 buttons in the same time.
The Display shows "Option= 0.00000
"
Press the + or – button to select the needed code.
If you can see the right code please press the Next button and the chosen option is active now.
• If activated - switch off the batch function with code "Option = 0.00005
", go out of the menu
and start the same procedure again.
• with "Pass = 0.02808 " you can chose TWO STAGE BATCH function with Preset and Prewarn
without automatic overflow control "aoc".
• or with "Pass = 0.02809 " you can chose SINGLE STAGE BATCH function with just Preset and
automatic overflow control "aoc" (Prewarn will be set automatically).
