RHOSS KCTR - Dimensions (clearance)

EN
44
Electrical connections Dimensions (clearance)
esc
set
31 .3
137.0 mm
96.5 mm
esc
set
31 .3
137.0 mm
96.5 mm
Note:
Once installed the KCTR verify the settings for the following parameters:
- Par 103 "LAn" = on, to enable use of the KCTR (required)
- PAr 101 "Mode" = 0, to set the mode switching (heating / cooling) using the KCTR (not required)
