6. Wall installation
KCTR is designed to be hung on a wall. Open
the front of KCTR separating it from the bottom,
making leverage with a screwdriver or similar tool
(see fig.1). After having removed the front, drill
2 holes 4 mm in diameter on the wall on which
KCTR will be fixed, at the intended distances
(see fig.2). Fix the bottom of the appliance to
the wall with the two screws. After having set
up connections, close the front of the keyboard
84mm
60mm
60mm
Fig. 1
by simply pressing it with your finger (see fig.3).
Do not install KCTR in places subject to high
humidity levels
and/or filth; it is suitable for use in environments
with ordinary or normal atmospheric pollution
levels. Leave a ventilated area around the coo-
ling slots of KCTR.
Fig. 2 Fig. 3
