ATTACH CARRIAGE BOLTS, WASHERS &
NUTS
TIGHTEN BOLTS ON LOWER MAST
Tighten both carriage bolts and lock nuts
5
6
7
8
TIGHTEN BOLTS ON UPPER MAST
Top of Spine—3/4” box wrench required
TIGHTEN BOLTS ON LOWER DIAGONAL
Tighten both carriage bolts and lock nuts
REMOVE LAG BOLTS THAT CONNECT
REAR COMB TO PALLET
Remove lag bolts—left and right side on rear
comb.
