53
Electric lock connections
cod.AC08003
12 V ac
I max 10VA
26 27
COM10
G
B
UP hinged doors instruction manual
Unlocking system:
In case of malfunctioning of the safety devices or the
automation, disconnect from power supply and operate the
door manually.
Warning: if equipped with electro lock, use the dedicated
key to unlock.
