ITM. / ART. 966690
RM20-2SS Traveler Grill
Cleaning Burner Tubes And Burner Ports
21
To reduce the chance of “FLASH-BACK” the procedure below should be followed at least once a month in late
summer or early fall when spiders are most active or when your grill has not been used for a period of time.
1. Turn all burner valves and gas tank valve to off position.
2. Detach the LP gas regulator assembly from your gas grill.
3. Remove cooking grids, flame tamers and grease tray from the grill.
4. Remove the screws from the underside of each burner and lift the burners up and away from the gas valve
orifice.
5.
Using an air hose or a bottle brush, run it through the burner tube several times to remove any debris.
6.
Replace burners, see illustration below.
Step 1. Locate the burner onto the orifice.
Step 2. Secure the main burner on the back wall of fire box with 2 screws.
7. Replace cooking grids, flame tamers and grease tray in the grill.
08/2
8/13
