• Bypass drawer connector ( page 115).
•
Vertical encoder wheel (
page 69).
•
Carriage Unit (
page 130).
•
Paper cassette.
1. The guide board ( x 3).
2. The gear [A] and bushing [B] (Gear x 1, x 1).
3. Remove the E-ring [A] and white bushing [B] on the opposite side ( x 1, x 1).
4. Replacement and Adjustment
128
