7
Manual Setting
If you cannot confirm the settings of the access point being used or the access point does not
support WPS, configure the wireless LAN settings manually.
You can configure the settings using Web Image Monitor or the control panel. This manual mainly
explains configuration using Web Image Monitor.
Configuring Settings Using Web Image Monitor
• Connect the machine and computer with an Ethernet cable before configuring the settings.
CHV620
• Check the security method employed by the access point being used.
• Check the machine's IP address.
the [ /Menu] key [Host Interface] [Network Setup] [IPv4 Address]
1. Launch the Web browser.
2. In the address bar, enter "http://(machine's IP address or host name)/".
3. Click [Administrator Login].
CHV621
A dialog box for entering the user name and password appears.
4. Enter the user name and password, and then click [OK].
If this is the first time to log in, enter "admin" as the user name and leave the password
blank.
To Next Page
