MO-C1 Training
Slide 24
Paper Holding Lever
The right side of the platen functions as the bypass feed
station.
If you lift the paper holding lever [1], the idle rollers above
the registration rollers [2] lift, so that cut-sheet paper can
be loaded on the right side of the platen.
Lowering the lever [3] clamps the paper in position for
paper feed.
No additional notes
