Ricoh GXR Brochure & Specs

This hinged-type lens cap opens and closes automatically when the lens barrel
extends and retracts. It increases shooting flexibility by eliminating the
inconvenience of having to remove/attach the lens cap. There is also no more
worry about lens cap loss. Bayonet-type mount.
Attaches to camera unit with a bayonet-type mount. Conversion lenses and an
exclusive hood can be attached. Universal filters (43 mm diameter), such as
polarization, cross-screen, and soft-focus filters, can also be attached to expand
range of expression.
This lithium-ion battery boasts the high capacity of 1700mAh while still being
small size and light weight. When traveling for business or pleasure, a charged
spare will provide peace of mind with respect to an unforeseen dead battery.
This is the charger for rechargeable battery DB-90. Small and light, it can be easily
carried for charging while away from home or office. With a rated input current of
100 to 240 V, 50/60 Hz, it can also be used overseas. Same as charger supplied
with camera body.
A slim two-point neck strap with the RICOH logo. Total length 1 m.
The SC-55S can be used when RICOH LENS S10 24-72 mm is attached to the
body, and the SC-55L is also available for use with GR LENS A12 50 mm.
12
System diagram
External Flash GF-1
Self-retaining Lens Cap LC-2
Hood & Adapter HA-3
Cable Switch CA-1
Soft Case SC-55S Soft Case SC-55L
Soft Case SC-55S Soft Case SC-55L
Neck Strap ST-3 Rechargeable Battery DB-90
Battery Charger BJ-9
Wide Conversion Lens DW-6
*Optional accessories for
RICOH LENS S10 24-72 mm
*Optional accessories for
RICOH LENS S10 24-72 mm
*Optional accessories for
RICOH LENS S10 24-72 mm
*Optional accessories for
RICOH LENS S10 24-72 mm
Teleconversion Lens TC-1
External Viewfinder VF-2
Be ready to charge anywhere. Battery Charger BJ-9
Stylish neck strap. Neck Strap ST-3
Protect your camera. Soft Cases SC-55S/SC-55L
For greater shooting flexibility. Self-retaining Lens Cap LC-2
Bayonet type for easy mounting. Hood & Adapter HA-3
Small size and high capacity. Rechargeable Battery DB-90
*Optional accessories for RICOH LENS S10 24-72 mm
*When the LC-2 is used, Hood & Adapter HA-3 cannot be used.
*Electric plug shapes vary by country and region. Please check in advance and bring an adapter if
necessary.
*Camera will not fit in case when LCD viewfinder VF-2 is attached to the body.
*Optional accessories for RICOH LENS S10 24-72 mm

Ricoh GXR Specifications

General

Megapixel	10 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	- \
Maximum image resolution	4288 x 2848 pixels
Still image resolution(s)	-
Interface	USB 2.0, NTSC, HDMI
Minimum RAM	512 MB
Minimum processor	500 MHz
Camera shutter speed	- s
Minimum storage drive space	160 MB
Compatible operating systems	Windows 2000/XP/Vista/7, Mac OS 9.0-9.2.2/X 10.1.2-10.6.4
Focal length (35mm film equivalent)	- mm
Optical zoom	3 x
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Spot Auto Focus
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Flash modes	Manual, Red-eye reduction, Slow synchronization
Internal memory	84 MB
Compatible memory cards	SD, SDHC
HD type	Not supported
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
PictBridge	No
USB version	2.0
Scene modes	Night, Portrait, Sports, Landscape (scenery)
Image editing	resizing, rotating
Camera playback	movie, single image
Self-timer delay	2 s
Playback zoom (max)	16 x
Product color	Black
Battery type	DB-90
Storage temperature (T-T)	3648 x 2736 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	37.5 mm
Width	113.9 mm
Height	70.2 mm
Weight	160 g
