Ricoh R10 Color Management Guide

2
2. Extract the file
1.
Download the LCD color balance adjustment file from the Ricoh website.
2. Double-click or right-click and select [Open] on the downloaded file.
• A dialog screen appears.
3. Click [OK].
• The folder [r10adj-XXX] (where XXX is the version number) is created and the file is
extracted to the folder. Check that [elaunch8] (adjusted value file) is inside the folder.
3. Copy the file to an SD memory card
There are two ways to copy the file into an SD memory card.
• With an SD memory card loaded in the camera, connect the camera and computer with the
provided USB cable, and copy the file to the SD memory card
• Using a card reader or a card writer, copy the file to an SD memory card (a card reader or card
writer is required)
To copy the file by connecting the camera and computer with the USB cable
1. If DC Software is installed on your Windows PC, check that DL-10 is not
active.
2. If DL-10 is active, right-click on the DL-10 icon in the task bar, and click
[Exit].
• If the DL-10 icon is not displayed in the task bar, you do not need to perform Step 2.
3. Load a battery with adequate remaining power into the camera.
4. Load the SD memory card into the camera, and turn the power on.
5. Display the camera’s Setup menu, select [Format [Card]], and press the
ADJ./OK button $.
elaunch8
elaunch8
For Windows For Macintosh

Ricoh R10 Specifications

General

Megapixel	10 MP
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	3648 x 2736 pixels
Optical zoom	7.1 x
Combined zoom	34.1 x
Focal length range	4.95 - 35.4 mm
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	Pentium III 500MHz
Camera shutter speed	1 - 1/2000 s
Minimum storage drive space	160 MB
Minimum system requirements	CD-ROM
Compatible operating systems	Windows 2000/Me/XP/Vista
Focal length (35mm film equivalent)	28 - 200 mm
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Macro focusing range (tele)	0.25 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
Auto Mode focusing range (tele)	1 - ∞ m
Auto Mode focusing range (wide)	0.3 - ∞ m
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.25 - 2 m
Flash range (wide)	0.2 - 3 m
Video formats supported	AVI
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Scene modes	Close-up (macro), Documents, Night landscape, Night portrait, Portrait, Landscape (scenery)
Image editing	resizing, trimming
White balance	auto, Cloudy, Fluorescent, Incandescent, manual
Camera playback	movie, single image
Self-timer delay	2, 2+10, 10 s
Product color	Brown
Battery life (CIPA standard)	300 shots
Number of batteries supported	1
Operating temperature (T-T)	0 - 40 °C
Compatible memory cards	sd
Light metering	Centre-weighted, Spot
Light exposure modes	Auto

Weight and Dimensions

Depth	26.1 mm
Width	102 mm
Height	58.3 mm
Weight	168 g
