Ricoh THETA V User Manual

RICOH THETA SC2 - User Guide
file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_03.html[2019/11/12 2:04:18]
Top
>
Preparation
>
Charging
Charging
The built-in battery needs to be charged before use.
1. Connect the camera to the computer using the provided USB cable.
The power lamp lights green when charging starts.
The power lamp is unlit when charging is complete.
2. Remove the USB cable after charging is complete.
Caution
Use the provided USB cable for charging. It may take time for the battery to charge or the battery may not charge
at all when a USB cable other than the provided USB cable is used.
Connect the cable directly to a USB port on the computer. Do not connect the cable via a USB hub. It may not be
possible to charge via some USB hubs.
When charging, be sure to insert and remove the USB cable while the computer is turned on. If the computer is
restarted while the USB cable is inserted, the computer may not recognize the camera.
Charging Time
The camera is charged in approx. 270 minutes (at 25°C (77°F)).
The time described above is a guide for full charging. The charging time differs according to the remaining battery
level.
If the remaining battery level is low, it may take time for the camera to be recognized by the computer.
← Back
▲ Back to Top
© 2019 Ricoh Company, Ltd. All Rights Reserved.
Note

Ricoh THETA V Specifications

General

Still Image Resolution	5376 x 2688
Video Resolution	3840 x 1920 (4K)
Lens Aperture	F2.0
Internal Storage	19GB
External Microphone Support	Yes
Dimensions	45.2 x 130.6 x 22.9 mm
Weight	121g
Image Sensor	1/2.3" CMOS
Effective Pixels	Approx. 12 megapixels
Video Resolution (Full HD)	1920 x 1080
Battery Life	Approx. 80 minutes
Battery Life (Still Images)	Approx. 300 shots
Connectivity	Wi-Fi, Bluetooth
Microphone	4-channel microphone
Camera Resolution	Approx. 14MP
Storage Media	Internal Memory Only
