3
1
Speaker
2
Battery/card cover
3
Lens
4
LCD panel
Displays the menu, shooting information, and captured
images. Touch operation is possible on this panel.
5
Shutter button
Shoots a still image or video when pressed.
6
Tripod mount hole
7
Power lamp
Lights blue when the power is on.
8
Power button
Turns the power on and off when pressed and held.
Turns the sleep mode on and off when pressed briefly.
9
Mode button
Switches the shooting mode.
Runs and terminates the installed plug-ins when pressed
and held.
0
USB terminal (USB Type-C)
Connects with other devices via the provided USB cable.
a
Microphone
b
Camera status lamp
Lights when shooting can be performed.
Be careful when handling the lens section. Always store the camera in
the provided soft case when the camera is not used.
