2 - 8
 LIFT CYCLE COUNTER
Refer to Figure 2-11. The cycle counter is located inside the hydraulic pump housing and visible
through a slot on the rear side. The counter advances each time the platform moves through a
complete cycle, which consists of the platform moving from the vehicle floor to the ground and
back to the floor. The number of cycles displayed is used to schedule maintenance operations.
CYCLE
COUNTER
FIGURE 2-11: CYCLE COUNTER
