ricoo S0722 - Step 5 b: Attaching Display to Wall Mount (Curved Back); Adapter Bracket Selection for Curved Back; Screw Adapter Brackets Onto TV; Step 6: Connecting Mount to Wall Plate

9
English
Deutsch
Mount two plastic washers and a screw nut, which were removed in step 1, on the top screw of the front panel, but do
not tighten. Between the two plastic washers should remain about 5mm distance.
And the two bottom screws provided with each a plastic washer (from step 1).
5mm
b
For displays with curved back
6
