RIDLEY 7E3 - Component Details: Fork and Handlebar; Fork Material and Dimensions; Fork Part Codes; Handlebar Material and Dimensions

Noah Fast Disc | Type 7E3
6
6. PARTS
6.1. FORK
This bike uses the Noah Fast aero fork.
6.1.1. MATERIAL
- Fork legs: Carbon
- Steerer tube: Carbon
6.1.2. DIMENSIONS
- Steerer tube length: 300 mm
- Headset: 1 1/8” upper ring – 1 1/4” lower ring
- Fork rake
:
o S, M, L and XL frame size: 45 mm
o XS frame size: 50 mm
- OLD (OverLock nut Distance): 100 mm
6.1.3. PART CODES
All the Noah Fast forks have a particular part code composed by the letters “FORCFR4ZA”, added by 3
numbers. The three numbers, depending on the design. Due to the big amount of forks we don’t list all
the numbers but you can contact your local dealer for more information if needed.
6.2. HANDLEBAR
6.2.1. MATERIAL
The Noah Fast handlebar is a full carbon handlebar.
6.2.2. DIMENSIONS
- Drop: 130 mm
- Reach: 75 mm
The handlebar is available in multiple sizes:
Stem length
Bar width
90
400
100
400
110
420
120
440
