RIDLEY 7E3 - Seat Post, Bottom Bracket, and Derailleur; Seat Post and Saddle Clamp; Bottom Bracket Specifications; Derailleur Mounts

Noah Fast Disc | Type 7E3
8
ridley part code
description
compatibility
SACWCSRIT003
Saddle Clamp 7x7mm
Standard round alloy rail
SACWCSRIT004
Saddle Clamp
7x9,6mm
Fizik oval carbon rail
SACWCSRIT005
Saddle Clamp
8x8,5mm
Standard oval carbon rail
6.6. BOTTOM BRACKET
The bottom bracket is designed for press fit 30 cups with a diameter of 46 mm and width of 68 mm. Below
bottom bracket cups are being used for the standard assembled bikes.
part code
brand
description
compatible cranksets
BBRPF3SRA001
SRAM
PRESS FIT 30 CUPS
SRAM 30 MM CRANKSETS
BBRPF3SRA003
SRAM
SRAM PF30 TO BSA ADAPTER 68MM
SHIMANO BSA 68 CRANKSETS
SRAM BSA 68 CRANKSETS
BBRPF3CAM002
CAMPAGNOLO
ULTRA TORQUE™ OS-FIT™
INTEGRATED CUPS BB30
68X46
CAMPAGNOLO ULTRA TORQUE
CRANKSETS
BBRPF3CAM003
CAMPAGNOLO
POWER TORQUE™ OS-FIT™
INTEGRATED CUPS BB30
68X46
CAMPAGNOLO POWER TORQUE
CRANKSETS
6.7. BRAKES
The Noah Fast is designed to use direct mount brakes.
6.8.
DERAILLEUR
6.8.1. FRONT
The Noah Fast frame uses a braze on clamp for the front derailleur.
6.8.2. REAR
For the rear derailleur, the Noah Fast frame uses a replaceable hanger (HAARCERID033).
6.4. SEAT POST
The Noah Fast frame is developed to use the Noah Fast aero seat post. To fix the seat post, the internal seat
post clamp (SPCAER4ZA005) has to be used. Pay attention to not exceed the maximum torque of 8 Nm for
the clamp and to respect a minimum insert of 10 cm for the seat post!
6.5. SADDLE CLAMP
There are three saddle clamps available:
