AARIA Multi MN
22
PMV_A
PMV_B
PMV_C
PMV_RE
1 2345678
PTC
SW3 SW4
SW2SW1
CN12CN13
(*) (**)
CN9
GND
CN11
CN8
Segment display
Display a segment
MAIN CONTROL BOARD
SCHEDA ELETTR. PRINCIPALE
P2(N)
POWER CIRCUIT
BOARD
SCHEDA
ELETTRONICA
CIRCUITO
DI POTENZA
Y/G
M
CN16 CN17
CN18
LED_G
LED_R
CN6
Fan motor
Motore ventilatore
T16A 250VAC
Fuse
Fusibile
M
CN14
LP
250VAC T3.15A
Fuse
Fusibile
CN5
4 way valve
Valvola a 4 vie
M
M
FG
Vsp
Vcc
CN7
CN15
HP
ACN
ACL
W
U
Compressor
Compressore
R
V
B
W
+
-
BR
BL
Capacitor
Capacitore
Reactor
Reattore
U
V
W
ACN
R1
N(-)
P(+)
MODULE BOARD
SCHEDA MODULO
DI POTENZA
ACL
R0
ON
4321
ON
M
COMM
Y/G
To indoor unit B
All'unità interna B
To indoor unit C
All'unità interna C
Y/G
To indoor unit A
All'unità interna A
2(L)
1(N)
3(C)
2(L)
1(N)
3(C)
2(L)
1(N)
3(C)
Vdc
LN
B
BR
A
R
Power
Alimentazione
CN2
CN23
CN21
SW6
SW5
CN1
CN2
CN4
CN3
CN7
CN5
CN6
CN10
Module temp. sensor
Sensore temp. modulo
CN12
P1(L)
CN1
RL1
Y/G
ON
4321
CN2
CN3
CN1
CN4
SW1
B
W
W
W
B
B
R
R
R
R
Y/G
W
B
P7
P8
P6
P5
P4
P3
W
B
1 2345678
ON
SW7
4
5
321
W
B
CN24 A-TC1
CN25 B-TC1
CN26 C-TC1
CN29 A-TC2
CN30 B-TC2
CN31 C-TC2
$
%
Central
controller
Controllo
centralizzato
R
BR
Electronic expansion valves
Valvole di espansione elettroniche
Defrost temp. sensor
Sensore temp. per sbrinamento
(*) Condensig temperature sensors for indoor units (gas pipe) A, B, C
(*) Sensori temperatura di condensazione linea del gas per unità interne A, B, C.
(**) Condensig temperature sensors for indoor units (liquid line) A, B, C
(**) Sensori temperatura di condensazione linea del liquido per unità interne A, B, C.
High pressure switch
Trasduttore di
alta pressione
Compr. disch. temp. sensor
Sensore temp. scarico compr.
Ambient temp. sensor
Sensore temp. ambiente
Suction temp. sensor
Sensore temp. aspirazione
Condensing temp. sensor
Sensore temp. condensazione
Pipe temp. sensor
Sensore temp. tubazione
Low pressure switch
Trasduttore di
bassa pressione
1 2 3 4 Settaggio di SW1 in caso di malfunzionamento / Definition of SW1 on Malfunction Display
OFF OFF OFF OFF Impostazione di fabbrica / State when out of factory (Normal Operating)
ON OFF OFF OFF Riscaldamento forzato / Compulsive Heating
OFF ON OFF OFF Raffreddamento forzato / Compulsive Cooling
OFF OFF ON OFF Funzionamento nominale / Rated Operating
Settaggio di SW5 / Definition of SW5
1 OFF
2 Parametro sbrinamento: ON
6° ; OFF 8°(Default) / Defrosting Parameter: ON 6° ; OFF 8°(Default)
3
Limite massima corrente: ON
Inferiore a 15A; OFF Taratura in funzione della macchina / Restrict of Max Current: ON Less than 15A; OFF
Adjust by machine types
4 OFF
AARIA MULTI 355 MN 5 OFF
6 ON
7
Modifica della frequenza : ON Disponibile; OFF Non disponibile (Default) / Frequency Modify: ON Available; OFF Unavailable (Default)
8 Funzionamento silenzioso: ON Disponibile; OFF Non disponibile (Default) / Quiet Operation: ON Available; OFF Unavailable (Default)
1 2 3 4 Controllo centralizzato / Centralized Control
OFF OFF OFF OFF Indirizzo=1 / Address=1
ON OFF OFF OFF Indirizzo=2 / Address=2
ON ON ON ON Indirizzo=16 / Address=16
--- --- --- --- ---------------
IT
355 MN - 370 MN
Definizione di SW6
* Le parti tratteggiate possono essere non disponibili
R Rosso
W Bianco
B Nero
BL Blu
OR Arancio
BR Marrone
Y/G Giallo/Verde
EN
355 MN - 370 MN
Definition of SW6
* The dashed part is optional.
R Red
W White
B Black
BL Blue
OR Orange
BR Brown
Y/G Yellow/Green
