Two options are available:
Option A. BIT (0 or 1, this is used to be set the status of
Q or F)
Option B. WORD (this is used to be set the value of AQ
or AF)
4. Record Index:
Here is used to set which line the CPU will access via this
Memory Read block
5. Register Params
Here is how to set the parameters of the register, all these
registers have a “write” property.
BIT data can be used to set the register “Q” and “F”.
Q: Digital Outputs
F: Digital Flag
WORD data can be used to set the register “AQ” and “AF”
AQ: Analogue Outputs
AF: Analogue Flags
Count
Sets the numbers of registers to be written.
For example
If the Memory Read block had been triggered, the Q1 of
PR-12 CPU will be set “1”.
Word to Bit
