Ethernet CPUs with Built-in Webserver
The new range of Ethernet CPUs from Rievtech have a
built-in webserver, which is incorporated in the following
models:
 ELC-12DC-DA-R-N
 EXM-12DC-DA-R-N(-4G)
 PR-12DC-**-**-N
 PR-12AC-R-N
 PR-18DC-**-**-N
 PR-18AC-R-N
 PR-26AC-R-N
 PR-26DC-***-**-*G
 PR-26DC-***-**-*WIFI
How to Distinguish Between New and Old CPU
Versions
Method A
If the label on the bottom of the CPU plastic housing has
a part number followed by (V2):
Method 2
Using xLogicsoft software, select Tools…transfer…Get PLC
version. If the hardware version is 1 then it is a new version:
Differences Between Old and New Versions of CPU
Items
New Version
Old Version
Network
Configuration
Tool
xLogicsoft or
eSMSConfig using menu
option Tools… Web
server config
DeviceManager
Software
TCP
Server/Client
Mode
Can work as BOTH a
Server and a Client at
the same time
Can work as EITHER
a Server or a Client
TCP
Connections
Maximum of 8
concurrent connections
Maximum of 1
connection
