Programmable Relay ● User Manual for ELC, EXM and PR Series 347 2020 v6.0 ● © Rievtech Co.,
Ltd. ● www.rievtech.com
Product Specifications
Specifications
CPU
Item PR-18AC-R PR-18DC-DA-R
PR-18DC-DA-RT
Output No 6 (Q1-Q6)
Relay output
10A
Yes
-
-
-
-
0.65A
4 (Q1-Q4) Relay output
2 (Q5-Q6)Transistor output
Resistive load 10A/Inductive load 2A Max. 0.3A per channel
AC 250V
DC 110V
DC 5-30V
1250VA
300W
105 Operations at Rated Resistive Load
Against short-circuits: None
Against overvoltages and overloads: None
107 Operations at No Load condition
Outputs
Output type
Continuous current
Max breaking voltage
Max allowable
power force
Electrical durability
expectancy
Built-in protections
Response time OperateTime: 15 ms max
ReleaseTime: 10 ms max
10Hz -
2Hz
10Hz
0.5Hz
10kHz
Q5, Q6 must have same
frequency when PWM works
< 0.5 % (20 % - 80 %) load at 10 mA
< 0.5% (20 % - 80 %) load at 10 mA
50mA
20m
0 to 100 %
-
-
-
-
-
-
Switch
frequency
PWM
Output
Mechanism
Resistor/light load
Sensitive load
PWM frequency
PWM accuracy at 120Hz
PWM accuracy at 500Hz
Max. cable length PWM
PWM cyclic ratio
Max. Breaking current
PWM
Max breaking current
- < 2V for I = 0.3A (at state 1)Voltage drop
Galvanic isolation
Relay Transistor
