Rigol DM3058

RIGOL
Quick Guide for DM3058/DM3058E
7
ENGLISH
To Connect Test Lead
1． DC Voltage Measurement
Connect test leads as shown in the following figure; red test
lead to the HI Terminal, black test lead to the LO Terminal.
2． AC Voltage Measurement
Connect test leads as shown in the following figure; red test
lead to the HI Terminal, black test lead to the LO Terminal.
DC Voltage
AC Voltage
