Rigol DSA800 Series Configuration Guide

To Configure DSA800 Series Spectrum Analyzer
The basic characteristics of DSA800 include:
 1.5 GHz/3.2 GHz/7.5 GHz maximum frequency
 1.5 GHz tracking generator (DSA815-TG)/3.2 GHz tracking generator (DSA832-TG)/7.5 GHz tracking
generator (DSA875-TG)
 Various interface configurations: LAN, USB Host, USB Device and GPIB (optional)
 8 inch high-resolution (800×480 pixels) display; clear and easy-to-operate graphical interface
 Compact and portable design
You can select the desired options and optional accessories to configure DSA800 according to your need. The
procedures are as follows.
1. Select the instrument model according to the frequency range
Explanation
Order No.
Other Information
Without TG
With TG
[1]
Spectrum Analyzer, 9 kHz to 1.5
GHz
DSA815 DSA815-TG
Provide standard accessories: Quick
Guide, CDROM (User’s Guide and
Programming Guide) and power cord.
Spectrum Analyzer, 9 kHz to 3.2
GHz
DSA832 DSA832-TG
Spectrum Analyzer, 9 kHz to 7.5
GHz
DSA875 DSA875-TG
2. Add other measurement functions
Explanation
Order No.
Other Information
Preamplifier, 100 kHz to 3.2 GHz
[2]
(only for DSA832)
PA-DSA832
When the signal under test is small,
turning on the preamplifier can reduce the
displayed average noise level so as to
measure even smaller signals.
Preamplifier, 100 kHz to 7.5 GHz
[2]
(only for DSA875)
PA-DSA875
Advanced Measurement Kit
[2]
AMK-DSA800
Provide various advanced measurement
functions: time domain power, adjacent
channel power, channel power, occupied
bandwidth, emission bandwidth,
carrier/noise ratio, harmonic distortion
and TOI.
3. Perform EMI pre-compliance test
Explanation
Order No.
Other Information
EMI Filter & Quasi-peak Detector
Kit
[2]
EMI-DSA800
Used for EMI pre-compliance test.
EMI Test System Software
EMI Test System
Note:
[1] If the tracking generator function is required, please order DSA815-TG/DSA832-TG/DSA875-TG spectrum analyzer (the
tracking generator is installed before the instrument leaves factory; return-to-factory installation is not supported).
[2] To install an option, acquire the option license according to the following procedures (first, order the desired option and the
option key is provided; then, log in RIGOL website (www.rigol.com), click “Customer Center” and select “License Generate” to
enter the software license generation interface; finally, input the option key, instrument serial number (refer to the User’s Guide to
acquire the serial number) and identifying code as well as click “Generate” to acquire the corresponding option license); then,
please install the corresponding option by referring to
DSA800 Firmware and Option Installation Instruction .
