Rigol PVA7000 Series User Manual

RIGOL
20 User Guide for PVA7000 Series Active Probe
Specifications
Technical Specifications
Item
PVA7250
Bandwidth
>2.5GHz
Rise Time
<140ps
System Bandwidth
2.5GHz
Input Capacitance
<1pF
Input Resistance
50kΩ±2% Differential
25kΩ±4% Single-ended
Input Dynamic Range
±2V
Input Common mode
Range
±6.25V DC to 100Hz
±1.25V >100Hz
Common Mode
Rejection Ratio
>45dB@1MHz
DC Attenuation
10:1 ±2%
Zero Offset Error
[1]
<30mV before calibration
<5mV after calibration
Offset Voltage Range
±2V
Offset Accuracy
[1]
<3% of current range
before calibration
<1% of current range
after calibration
Input Noise
3.8mVpp
Propagation Delay
7ns
Max Input Voltage
30V Peak CAT I
[2]
Electrostatic Protection
(HBM)
>8kV
