Rigol RSA3030 Performance Verification Guide

Appendix RIGOL
RSA3000 Performance Verification Guide
3
Second Harmonic Distortion Test:
Output Frequency of
Signal Generator
Delta
Calculation Result
[1]
Limit
Pass/Fail
300 MHz
>45 dBm
1 GHz
Note
[1]
: Calculation Result = -20 dBm - Delta (-20 dBm is the level input into the mixer).
TOI Distortion Test:
Center Frequency
Delta
Calculation Result
[1]
Limit
Pass/Fail
299.8 MHz
>10 dBm, >+15
dBm (typical)
300.4 MHz
999.8 MHz
1.0004 GHz
Note
[1]
: Calculation Result = -20 dBm - Delta/2 (-20 dBm is the level input into the mixer).
1 dB Gain Compression Test:
Output Amplitude of
Signal Generator B
Measurement
Result A1
Measurement
Result A2
Calculation
Result
[1]
Limit
Pass/Fail
0 dBm
<1 dBm
Note
[1]
: Calculation Result = A1 - A2.
Input Attenuation Switching Uncertainty Test:
System Error Reference Value
Global Error Reference Value
Reference
Level
Internal
Attenuator
Program-
controlled
Attenuator
System
Error
[1]
Global
Error
[2]
Uncertainty
[3]
Limit
Pass/Fail
-10 dBm
0 dB
30 dB
<0.3 dB
-9 dBm
1 dB
29 dB
-8 dBm
2 dB
28 dB
-7 dBm
3 dB
27 dB
-6 dBm
4 dB
26 dB
-5 dBm
5 dB
25 dB
-4 dBm
6 dB
24 dB
-3 dBm
7 dB
23 dB
-2 dBm
8 dB
22 dB
-1 dBm
9 dB
21 dB
0 dBm
10 dB
20 dB
1 dBm
11 dB
19 dB
2 dBm
12 dB
18 dB
3 dBm
13 dB
17 dB
4 dBm
14 dB
16 dB
5 dBm
15 dB
15 dB
