Chapter 2 Functions of the Front Panel of GPSA RIGOL
RSA3000 User Guide 2-71
waveform display area.
If the marker is not visible in the selected area, extend the marker line to the
display area for better observation. This function is useful for the marker outside
the display area. The marker extension line can better display the amplitude of
the marker, making it easy for you to observe and compare.
Couple Markers
Enables or disables the couple marker function.
Remarks:
When this function is enabled, moving any marker will enable other markers
(except the Fixed or Off marker) to move with it.
The fixed marker does not move along with other marker, but if the fixed marker
moves, other non-fixed markers will move with it.
Marker Table
Enables or disables the marker table.
When it is set to "On", the lower section of the split screen displays all the enabled
markers in the form of lists. They include marker number, trace number, marker
readout type, X-axis readout, and amplitude. Through this table, you can view the
measurement values of multiple points.
Note: The marker table currently opened can be saved to the internal or external
memory, and you can recall it at any time if you need. Press Save to save it
according to descriptions in "Save".
